Stretch Hood System

Innova Group - Stretch Hood Systems

Stretch Hood System

Stretch Hoods are a highly efficient solution that provide maximum load stability and protection for your products.

Innova Group - Stretch Hood Machines

innova-2024-11-29(2)

innova-2024-11-29(1)

innova-2024-11-29(3)

Stretch Hoods - Innova Group

Stretch Hooding technology uses tubular film which is stretched to conform to nearly any load shape, sealing and fully protecting products against external elements. Stretch hood systems offer increased wrapping speeds and improved total load protection during transportation.

Features

Up to 120 + pallets/hour
Film thickness: 60 – 130 μm
Stretches over various pallet sizes
Max load dimensions: 2,000 x 1,400 mm / 80 x 55 inches
Max load height: 2,000 mm / 80 inches
Max load weight: 2,000 kg / 4,400 Lb
Number of reels: 1-2

Industries

Alcohol & Spirits
Bakery
Beverage
Cannabis
Chemicals
Cleaning Products
Confectionery

Construction
Cosmetics
Dairy
Food
Industrial
Non-Food
Pet food
Pharmaceuticals

Read more

Share on Social

Related Products

UPA II Print & Apply Labeler

C16 Case Sealer

Related Consumables

Packaging Tape

Excise Stamp Labeler for Pre-Roll Tubes

Tax Stamp Labeler for Cannabis Tubes

Excise Stamp Labeler for Pre-Roll Tubes

The Link-Pack Excise Stamp Labeler is an oriented wrap labeler explicitly adapted to apply pressure-sensitive pre-glued tax stamps to pre-roll roll tubes.

Tax Stamp Labeler for Cannabis Tubes

Designed to automatically feed the pre-roll tubes onto a horizontal roller conveyor, and transports them towards the labeling station equipped with a vision assisted orientation. Labeled rotate on the conveyor and are wiped down to secure the excise stamp to the tube.

Features

Reaching speeds of 35-40 tubes per minute
Tube magazine with automatic indexing wheel
Heavy-Duty Tubular Stainless Steel Construction
Nema 4X Stainless Steel Control Box
Allen Bradley PLC & HMI
Herma 500 servo label head
Recipe management via touch screen

Options

Additional label applicator for information labels
Vision inspection (OCR/OCV)
Low Label Web Sensor
Critical Care Parts
Extended Length Conveyor
Accumulation Table

Industries

Cannabis
CBD
Nutraceutical

Share on Social

Related Products

Floor Scales

Pail Filling Machine

Related Consumables

Packaging Tape

Cannabis Labeling Machines Excise Stamps Tax Stamp Labeler

Horizontal Strapping System

Horizontal Strapping System

Innova’s automatic horizontal pallet strapping machine is engineered to deliver flexible and customizable strapping solutions tailored to your specific pallet needs. It offers the capability to configure both the position and the number of straps, allowing it to adapt to various pallet sizes and shapes with ease.

Horizontal Pallet Stapping(1)

Horizontal Pallet Stapping(3)

Horizontal Pallet Stapping(2)

Horizontal Pallet Strapping System

This horizontal strapping machine features an anti-vibration portal frame constructed with a solid four-pillar design. The frame enhances the overall robustness of the system, providing additional strength and stability throughout the strapping process. It can be fitted with an optional automatic lateral compactor to achieve a perfectly secure load by applying pressure from the sides, further tightening the straps and reducing any potential movement during transport.

Features

60 pallets /hour
Operating Width: Between 3/8″ to 1/2″ (9 – 12 mm)
Easy Accessible Grace Port
Strapping Materials: Polyester (PET) or Polypropylene (PP)
Max Load Dimensions: Standard: 53″ x 48″ // 1.350 x 1220 mm // Big formats: 87″ x 60″ // 2.200 x 1.500 mm
Max Load Height: 78 in // 2.000 mm (adaptable to other loads)
Max Load Weight: 4.400 lbs // 2.000 kg (adaptable to other loads)
Strapping Head: ODEN strapping head, resistance welded
Stapping Uncoiler: Motorized with buffer effect

Industries

Alcohol & Spirits
Bakery
Beverage
Chemicals
Cleaning Products

Confectionery
Construction
Cosmetics
Dairy
Food
Industrial
Non-Food
Pet food
Pharmaceuticals

Read more

Share on Social

Related Products

UPA II Print & Apply Labeler

Automatic Pouch Labeler

CE35 Case Erector

Related Consumables

Packaging Tape

Packaging Adhesives

Horizontal Pallet Stapping System Load Stabilizing pallet strapping

Vertical Strapping System

Vertical Strapping System

Innova’s automatic vertical pallet strapping machine is a versatile solution designed to handle a wide range of pallet sizes and configurations. It offers the ability to strap loads on either 2 or 4 sides, depending on the specific requirements of the product and packaging.

Vertical Pallet Strapping System

Untitled design(5)

Untitled design(3)

Untitled design(4)

The machine is equipped with a 90º swivel system that allows strapping in one or two directions, significantly enhancing load fastening and ensuring comprehensive security for the palletized goods.

Features

40 pallets /hour
Operating Width: Between 3/8″ to 1/2″ (9 – 12 mm)
Stapping Materials: Polyester (PET) or Polypropylene (PP)
Max Load Dimensions: Standard width: 47″ // 1220 mm // Big formats: 80″ // 2.050 mm
Max Load Height: Between 8″ and 70″ // 200 mm y 1.800 mm (adaptable to other loads)
Max Load Weight: 4.400 lbs // 2.000 kg (adaptable to other loads)
Strapping Head: ODEN strapping head, resistance welded
Strapping Uncoiler: Motorized with buffer effect

Industries

Alcohol & Spirits
Bakery
Beverage
Chemicals
Cleaning Products

Confectionery
Construction
Cosmetics
Dairy
Food
Industrial
Non-Food
Pet food
Pharmaceuticals

Read more

Share on Social

Related Products

UPA II Print & Apply Labeler

Soluta – Pressure Sensitive Labeler

CE35 Case Erector

Related Consumables

Packaging Tape

Packaging Adhesives

pallet strapping Vertical Strapping

ADM | Pack Ex Montreal

ADM | Pack Ex Montreal

Gear Up For A Great Show!

Join us at ADM Montreal where we’ll be showcasing some of our best-in-class packaging solutions! From product inspection units to case forming and sealing machines, we’ve got live demos lined up just for you. It’s the perfect opportunity to see these machines up close and in action!

We know how busy you are, but We can’t wait to connect with you in person and discuss how we can work together to take your business to the next level. See you there!

Why visit us?

✔ Live demonstrations of industry-leading machines
✔ Expert advice from our team of specialists
✔ A chance to discover how we can help optimize your packaging processes and boost efficiency

We know how busy you are, but this is an event you won’t want to miss. So, pencil it in, and we’ll make sure to give you a tour of the exciting innovations we have in store.

Meet Some of our Trusted Partners

Share on Social

Guide Rails Metal Detection Thin Slit Curtains X-Ray

Shrink Hood System

Stretch Hoods - Innova Group

Shrink Hood System

Ensure your products receive the highest level of protection and airtight sealing with this state-of-the-art shrink hooding machine.

Stretch Hoods - Innova Group

Innova Group Stretch Hood

innova-2024-10-02(10)

innova-2024-10-02(8)

This system is composed of an automated hooding mechanism paired with an oven that heats the shrink film to a precise 280ºC, causing the film to contract and perfectly conform to the shape of the load. As a result, your products are fully encapsulated, providing a secure and tight-fitting wrap that enhances both safety and durability during handling and transportation.

Features

Up to 60 pallets/hour
Film thickness: 80 – 150 μm
Heat shrink various pallet sizes
Fully adaptable to the pallet
Better hold and stabilization
Fully protected and watertight loads

Industries

Alcohol & Spirits
Bakery
Beverage
Cannabis
Chemicals
Cleaning Products
Confectionery

Construction
Cosmetics
Dairy
Food
Industrial
Non-Food
Pet food
Pharmaceuticals

Read more

Share on Social

Related Products

UPA II Print & Apply Labeler

C16 Case Sealer

Related Consumables

Packaging Tape
